CS4344-10-Pin, 24-Bit, 192 kHz Stereo D/A Converter
The CS4344 family members (CS4344, CS4345, and
CS4348) are complete, stereo digital-to-analog output
systems including interpolation, multibit D/A conversion
and output analog filtering in a 10-pin package. The
CS4344 family supports major audio data interface formats.
Individual devices differ only in the supported
interface format.
The CS4344 family is based on a fourth-order multibit
delta-sigma modulator with a linear analog low-pass filter.
This family also includes autospeed mode detection
using both sample rate and master clock ratio as a
method of auto-selecting sampling rates between 2 kHz
and 200 kHz.
The CS4344 family contains on-chip digital deemphasis,
operates from a single +3.3 V or +5 V power supply,
and requires minimal support circuitry. These features
are ideal for DVD players & recorders, digital televisions,
home theater and set top box products, and
automotive audio systems.
The CS4344 family is available in a 10-pin TSSOP
package in both Commercial (-10 to +85 °C) and Automotive
grades (-40 to +85 °C). See Section 8. “Ordering
Information” on page 23 for complete details.
